General
Maximum Thrust	280kg(550Lbs) Linear Thrust
Working Voltage	DC 12V
Working Current	340mA
Dimension of Lock Body	238mm × 45mm × 25mm (9.4'' × 1.8'' ×1.0')
Dimension of Armature Plate	182mm × 38mm × 12.5mm (7.2'' × 1.5'' × 0.5')
Suitable Doors	Wooden Door, Glass Door, Metal Door, Fireproof Door
LED Indicator	Green (Work Status)
Lock Body	Eco-friendly Zinc Electroplating Operated
Shell	Hard Anodizing Electroplating Operated
Armature Plate	Eco-friendly Zinc Electroplating Operated
Working Humidity	0 to 95% (relative humidity)
Working Temperature	-10° C to 55° C (14° F to 131° F)
Weight	2.1kg(4.63lb)
