Operating voltage	9 - 30 V DC
Max. current consumption	33 mA
Monitoring	Reverse polarity
Dimensions (W x H)	Ø 93 x 91 mm
Weight	250 g
Housing material	ABS V0, PC
Color	Red, RAL 3001 White, RAL 9010
Permissible operating temperature	-25 - 70 °C
Permissible rel. humidity	EN 54-3
Protection class as per EN 60529	IP 65
Max. sound pressure at 12 V	105 ± 3 dB(A)
Max. sound pressure at 24 V	112 ± 3 dB(A)
